Bose L1 Pro16

Bose

Portable Line Array System

BOSE L1 PRO / SUB APPLICATION GUIDE (PDF)

$2,799.00 inc. GST

$3,299.00 for 3 item(s)

USED!

BOSE L1 PRO / SUB APPLICATION GUIDE (PDF)

A balance of power and portability, the L1 Pro16 portable line array is a streamlined system with high output and extended low frequency range.

With a 16-driver articulated J-shape line array, the L1 Pro16 delivers 180-degree horizontal sound coverage, great for small-to-medium sized clubs, bars, and other venues.

An integrated subwoofer with a RaceTrack driver delivers powerful bass without the bulk; a built-in multi-channel mixer offers EQ, reverb, and phantom power, plus Bluetooth® streaming and access to the full library of ToneMatch presets, and the intuitive L1 Mix app places wireless control in your hands from your smartphone.

For DJs, singer-songwriters, and small ensembles, the L1 Pro16 gives you expanded bandwidth and supreme clarity — the power to sound your best and simply perform.



SKU: bose-l1-pro16 Categories: , , , , , , ,
Weight 18 kg
Dimensions 111 × 65 × 46 cm
Brands

Bose

General

  • Portable line array system for professional performance

  • Compact modular design for easy transport and setup

  • Ideal for singer-songwriters, bands, and DJs

Audio

  • Speaker Configuration: J-shaped array with 16 × 2″ neodymium drivers

  • Coverage Pattern: 180° horizontal, 40° vertical dispersion

  • Integrated Subwoofer: 10″ × 18″ RaceTrack driver

  • Frequency Response (-3 dB): 42 Hz – 16 kHz

  • Maximum SPL: 118 dB

Mixer

  • Channels: 3 (2 mic/line + 1 aux/Bluetooth)

  • Inputs:

    • 2 × XLR-¼” combo inputs (with phantom power)

    • 1 × ¼” aux input

    • 1 × ⅛” (3.5 mm) stereo input

    • Bluetooth® audio input

  • Outputs:

    • 1 × Balanced XLR line output

    • 1 × ToneMatch port (power + digital audio)

  • Per Channel Controls: Volume, Tone, Reverb

  • System EQ Presets: Live Music, Recorded Music, Speech

Connectivity

  • Bluetooth® audio streaming

  • Wireless control via L1 Mix app (iOS/Android)

  • ToneMatch port for connecting Bose T4S/T8S mixers

Power

  • Power Supply: AC mains (region dependent)

  • Power Consumption: Approx. 300 W

Physical

  • Dimensions (H × W × D): 2010 mm × 355 mm × 456 mm (79.1″ × 14″ × 18″)

  • Weight: 24.4 kg (53.8 lbs)

Included Items

  • L1 Pro16 power stand (base)

  • L1 Pro16 array extension

  • Power cable

  • Carry bag

  • Quick start guide
